Powder Coated Cable Tray Supplier & Exporter in UAE
Superfab Inc. is a Powder Coated Cable Tray supplier and exporter to UAE, manufacturing in Mumbai, India and shipping to projects in Dubai, Abu Dhabi, Sharjah, Ras Al Khaimah, Jebel Ali Free Zone and KIZAD.
Our powder coated cable trays are GI or MS trays finished in RAL shades, so power, control, fire-alarm and data routes can be colour coded – available with covers and fittings coated in the same shade.
The UAE is the largest Gulf market for Indian cable trays, driven by oil & gas and petrochemical expansion in Abu Dhabi, Dubai's commercial and hospitality towers, utilities and desalination plants, data centres and the industrial free zones at Jebel Ali and KIZAD. Powder coated trays are used in UAE for visible MEP routes in hotels, malls and towers, where colour-coded or visible cable routes are needed.
Orders for the UAE are packed for sea freight and shipped from Nhava Sheva (JNPT), Mumbai to Jebel Ali or Khalifa Port – one of the shortest and most frequent sea routes from India. Commercial invoice, packing list and certificate of origin are prepared for each shipment.
Need a price for Powder Coated Cable Trays in UAE? +91 98208 02872 Request a Quote
Powder Coated Cable Trays for UAE's Industries
| Sector | Key areas in UAE | Typical powder coated cable tray routes |
|---|---|---|
| Oil, gas & petrochemicals | Abu Dhabi, Ruwais, Fujairah | Process-area power, control and instrumentation cables |
| Commercial towers & hospitality | Dubai, Abu Dhabi, Sharjah | Risers, basements, car parks and MEP services |
| Utilities & desalination | Jebel Ali, Taweelah | Power-plant and pump-station cable routes |
| Data centres | Dubai, Abu Dhabi | White-space power and data cable routes |
| Free zones & industry | JAFZA, KIZAD, RAK | Warehouse, factory and utility cabling |
Choosing the Right Powder Coated Cable Tray Finish for UAE
The UAE combines extreme heat, strong UV, wind-blown sand and humid, salty coastal air, so hot-dip galvanised trays are the minimum for outdoor runs, SS 316 or aluminium is preferred near the sea and in process areas, and pre-galvanised trays are limited to air-conditioned interiors. For powder coated cable trays, we generally recommend powder coating over a galvanised base for semi-exposed areas, and powder coated MS or GI for dry, visible indoor routes in commercial buildings. Share your site conditions and our team will confirm the material, thickness and finish before quoting.
How We Supply Powder Coated Cable Trays to UAE
- Send your requirement – tray type, width × height × thickness, finish, quantity in metres and the fittings list, or your BOQ / drawing.
- Technical check & quotation – we confirm sizes, part numbers and finish, and send a quotation.
- Manufacturing in Mumbai – trays, fittings and covers are made to the approved sizes and inspected before dispatch.
- Export packing & shipment – packed for sea freight and shipped from Nhava Sheva (JNPT), Mumbai to Jebel Ali and Khalifa Port.
Powder Coated Cable Trays – Available Tray Types Exported to UAE
Powder Coated Cable Trays – Technical Specifications
| Material / finish | Powder coated on GI or MS base, RAL shade as specified |
|---|---|
| Tray types | Perforated (SIP1–SIP6) and ladder (SIL1–SIL6), with matching covers and fittings |
| Standard lengths | 2500 mm and 3000 mm; bend radius 300–1200 mm |
| Widths | Perforated 50–1200 mm; ladder 100–1500 mm |
| Height / thickness | 15–150 mm flange height; 1.0–3.0 mm sheet thickness |
| Standards | Manufactured to NEMA and IS practice; custom sizes on request |
Sizes above are standard catalogue ranges; non-standard sizes are made to drawing. Download the catalogue for part numbering.
Get a quote for Powder Coated Cable Trays in UAE
Share your tray size, finish and quantity. We supply across India and export worldwide.
Powder Coated Cable Trays in UAE – Frequently Asked Questions
Do you export Powder Coated Cable Trays to UAE?
Yes. Superfab Inc. manufactures Powder Coated Cable Trays in Mumbai, India and exports them to EPC contractors, panel builders and end users in UAE, including Dubai, Abu Dhabi, Sharjah, Ras Al Khaimah, Jebel Ali Free Zone and KIZAD.
How are Powder Coated Cable Trays shipped to UAE?
Orders for the UAE are packed for sea freight and shipped from Nhava Sheva (JNPT), Mumbai to Jebel Ali or Khalifa Port – one of the shortest and most frequent sea routes from India. Commercial invoice, packing list and certificate of origin are prepared for each shipment.
Which Powder Coated Cable Tray finish is best for projects in UAE?
The UAE combines extreme heat, strong UV, wind-blown sand and humid, salty coastal air, so hot-dip galvanised trays are the minimum for outdoor runs, SS 316 or aluminium is preferred near the sea and in process areas, and pre-galvanised trays are limited to air-conditioned interiors. For powder coated cable trays we generally recommend powder coating over a galvanised base for semi-exposed areas, and powder coated MS or GI for dry, visible indoor routes in commercial buildings.
What are powder coated cable trays?
They are GI or MS cable trays finished with an electrostatically applied, oven-cured powder coat for extra protection and colour.
Which colours are available?
Trays can be coated in the RAL shade specified for your project, for example red for fire alarm or grey for power.
Is powder coating suitable outdoors?
For outdoor runs, powder coating over a galvanised base is recommended.
